Product Description
| SKU | VT-SE-1801 |
|---|---|
| Magnification | 1 – 8 |
| Objective Lens Diameter | 24 mm |
| Eye Relief | 3.9 inches |
| Field of View | 113.6–14.1 feet/100 yards |
| Tube Size | 30 mm |
| Turret Style | Capped |
| Adjustment Graduation | 1/4 MOA |
| Travel per Rotation | 25 MOA |
| Max Elevation Adjustment | 145 MOA |
| Max Windage Adjustment | 145 MOA |
| Parallax Setting | Fixed @125 yards |
| Length | 10.4 inches |
| Weight | 23.9 ounces |
| Riflescope Manual (.pdf) | Download PDF |
| Reticle Manual (.pdf) | Download PDF |
- Flip Caps
- Throw Lever
- Lens Cloth
- CR2032 Battery
- 2mm Hex Wrench
- Sunshade
| Lengths | ||||
| L1 | L2 | L3 | L4 | L5 |
| 10.4 | 6 | 3.8 | 2.5 | 1.9 |
| Heights | |
| H1 | H2 |
| 1.89 | 1.93 |
Dimensions measured in inches.
Optical Features | |
| Illuminated Reticle | Provides precise aiming under low-light conditions |
| Fully Multi-Coated | Proprietary coatings increase light transmission with multiple anti-reflective coatings on all air-to-glass surfaces. |
| First Focal Plane Reticle | Scale of reticle remains in proportion to the zoomed image. Constant subtensions allow accurate holdover and ranging at all magnifications. |
| Glass-Etched Reticle | Allows for intricate reticle design. Protected between two layers of glass for optimum durability and reliability. |
Construction Features | |
| ArmorTek ® | Ultra-hard, scratch-resistant coating protects exterior lenses from scratches, oil and dirt. |
| Shockproof | Rugged construction withstands recoil and impact. |
| Waterproof | O-ring seals prevent moisture, dust and debris from penetrating the binocular for reliable performance in all environments. |
| Fogproof | Nitrogen gas purging prevents internal fogging over a wide range of temperatures. |
| Low-Glare Matte Black Anodized | Corrosion and wear resistant anodization provides low-glare matte surface and helps camouflage the shooter's position. |
| Aircraft-Grade Aluminum | Constructed from a solid block of aircraft-grade aluminum for strength and rigidity. |
| Single-Piece Tube | Maximizes alignment for improved accuracy and optimum visual performance, as well as ensures strength and waterproofness. |
Convenience Features | |
| Fast Focus Eyepiece | Allows quick and easy reticle focusing. |
| Throw Lever | The included throw lever can be installed for quick and easy magnification adjustments. |
